SRC1KI-IN (INBUILT BATTERY)

APC Smart-UPS RC 1000VA, 230V, 4x India 3-pin 6A outlets, harsh environment

Enquire Now
Categories: ,

Specifications

Overview
Lead time Usually in Stock
Main
Run time for load 800 W
Min-max: 80-800 W
8min 2s
Max. Capacity Used
100 %
Main Input Voltage 230 V
Main Output Voltage 230 V
Other Output Voltage 220 V
240 V
rated power in W 800 W
rated power in VA 1000 VA
nb of power socket outlets 4 India 3-pin 6A
cable length 1.52 m
number of cables 1
battery type Lead-acid battery
provided equipment Smart UPS signalling RS-232 cable
User manual
Warranty card
General
Number of power module free slots 0
Number of power module filled slots 0
redundant No
Physical
colour Black
height 22 cm
width 14.5 cm
depth 40 cm
net weight 13.5 kg
mounting preference No preference
mounting mode Not rack-mountable
two post mountable 0
USB compatible No
Input
network frequency 40…70 Hz
plug standard India 3-pin 6A
input voltage limits 110…280 V half load
switching current capacity 10 A
Output
Maximum configurable power in W 800 W
harmonic distortion Less than 2 %
output frequency 50/60 Hz +/- 3 Hz sync to mains
crest factor 3 : 1
UPS type Double conversion online
Wave type Sine wave
bypass type Built-in bypass
efficiency 90 % (full load)
88 % (half load)
Maximum configurable power in VA 1000 VA
Environmental
ambient air temperature for operation 0…40 °C
relative humidity 0…95 %
operating altitude 0…3000 ft
ambient air temperature for storage -20…60 °C
storage Relative Humidity 0…95 %
storage altitude 0.00…4572.00 m
Batteries & Runtime
Run Time View Runtime Graph

action_new_window
number of battery filled slots 0
number of battery free slots 0
Battery recharge time 6 h
battery charger power 54 W rated
Battery power in VAH 324 VAh capacity
324 VAh runtime
extended runtime 0
Communications & Management
control panel LED status display with on line : on battery : replace battery and overload indicators
alarm Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Packing Units
Package 1 Weight 14.5 kg
Package 1 Height 34 cm
Package 1 width 23.5 cm
Package 1 Length 47.8 cm
Number of Units in Package 3 50
Package 3 Weight 765 kg
Package 3 Height 195.2 cm
Package 3 width 100 cm
Package 3 Length 120 cm
Contractual warranty
Warranty 2 years repair or replace
